TruHeat® Furnaces
Armil CFS manufactures TruHeat® pre-engineered gas fired box furnaces for use in a variety of industries.
True Heat Furnaces can be used at operating temperatures from 450°F to 2200°F. TruHeat furnaces include Allen Bradley PLC/HMI, Honeywell limit controllers, and Low NOx Eclipse burners. Furnaces come with a standard 6” thick Fiberfrax ceramic fiber lining, with an optional 9”thick lining available. TruHeat furnaces come standard with an insulated flue, a low NOx Tru-Burn afterburner is also available.
Click Here for the TruHeat® Furnaces Spec Sheet
Common Applications Include:
- Heat treating
- Stress Relieving
- Annealing
- Ceramics
- Investment Casting
- Burn out
- Pre Heat
- Incineration
- Forging
- Reheat
- Die heating
Tru-Heat ® Box Furnace for Stress Relieving
- Chamber size 5’ wide x 4’ deep x 4’ high
- Operating temperature 600°F—1100°F
Tru-Heat® Small Box Furnace
- 3’ wide x 2 ft deep x 2 ft high
- 1800oF—2300oF operating temp
Tru-Heat Box Furnace with Afterburner
- 14’ x 9’ x 4’ work chamber
- Operating temperature up to 2250oF
Tru-Heat® 2 Chamber Box Furnace
- Each chamber is 4’w x 5’d x 4’h
- 2 separate combustion systems with 1 central control system
- Operating temperature of 450°F—2200°F
